P20 Full Color Operating System Windows 2000 Stadium Outdoor LED Display HTGJ-OF20 manufacturer from China HongKong HanTang Optoelectronics Co.,Limited

P20 Full Color Operating System Windows 2000 Stadium Outdoor LED Display

Place of Origin:

Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HTGJ-OF20

P20 Full Color Operating System Windows 2000 Stadium Outdo

P20 Full Color Operating System Windows 2000 Stadium Outdoor LED Display

Features.
1. Vivid pictures
2. Big viewing angle distance
3. Relative low price
4.Two years warranty

Technical Parameters of P20 full color outdoor LED Display
Usage	Outdoor
Pitch(mm)	20
Pixel Constitute	2R1G1PB
LED--Opto+Silan	R:λd(625-630nm) G:λd(522.5-525nm) B:λd(467.5-470nm) R:(450-500mcd) G:(1600-1800mcd) G:(350-400mcd)
Pixel Density(dots/M2)	2500
Module Size(mm)	320*160
Module Resolution	16*8
Recommended Minimum Viewing Distance(m)	>=18
Viewing Angle(°C)	V40, H110
Average Power Consumption	500W/M2
Brightness (white balance)	5000cd/M2
Size of cabinet(mm)	128096080
Weight of cabinet	60kg/M2
Cabinet pixels(dot)	64*48
Frame frequency	≥60Hz
Refresh rate	≥360Hz
Grey color	≥16.7M
Brightness adjustment	256 grade manual, 8 grade automatic
Average NO failure time	5000 hours
Life span	100000 hours
Working temperature	-30 °C +60°C
Driving Voltage	5VDC
Working Voltage	110 to 220VDC
Scan Mode	static
Display Function	Video, Animation, Graphics, other
Operating system	Windows (2000/XP/Vista)
Control distance	CAT5 cable:<100 m; Single fiber:<10 km
